Medical Waste Transfer Vehicle,Medical Waste Refrigerated Transport Vehicle,Medical Waste Collection Vehicle,Medical waste transfer vehicles are also known as medical refuse transport vehicles, medical waste collection vehicles, medical waste transfer trucks, medical waste transfer Vans etc. Ideal for your medical waste disposal and collection fleet.
| Back door | Two isolation doors |
| Side door | single-door |
| Tank volume (m3) | 15.2 |
| Overall size (mm) | 5,995×2,045×3,130 |
| Cargo size (mm) | 4,000×1,900×2,000 |
| Total mass (kg) | 4,495 |
| Rated mass (kg) | 1,215 |
| Cube weight (kg) | 3,150 |
| Number of axes | 2 |
| Wheelbase (mm) | 3,360 |
| Chassis technical parameters | |
| Number of tires | 6 |
| Tire size | 7.00R16LT 10PR |
| Wheel base (front/rear) mm | 1,400/1,425 |
| Number of leaf springs(front and back) | 4/4+4 |
| Fuel type | diesel |
| Chassis manufacturer | Jiangling Motors Co., Ltd. (JMC) |
| Engine model | JX4932ZLQ6D |
| Power(kW) | 90kW |
Customized Special specifications accepted.
Characteristics
The vehicle color is white, the outer layer use fiberglass, the inner layer use stainless steel, and the middle layer is polyurethane insulation layer. It equipped with special UV lamp for disinfection, spray sterilizer device, stainless steel fixing slot, and stainless steel liquid collection tank.
Because the box adopts closed transportation, the back door is double-closed structure to prevent the spread of bacteria and toxic gases of medical waste. The medical waste transfer vehicle must be transported at low temperatures, so the medical waste transfer vehicle is equipped with a refrigeration unit, the minimum temperature can reach -18 degrees, and the temperature can be set. The inner wall stainless steel plate can be used for corrosive disinfection, the bottom and corners of the car are smooth, so the dead corners can also be cleaned and disinfected.
The original chassis, the brand is Jiangling, with a set of chassis tools, five-speed transmission, 700R16 steel wire tires, electric glass lifting, direction power, liquid brake, in line with the new blue brand dangerous goods standards, anti-collision/lane departure dual warning system, front disc brake, ABS, speed limit 80km/h, front exhaust pipe.
Aluminum alloy profile edge reinforcement, door frame and lock parts are all stainless steel, equipped with electrostatic belt, fire extinguisher, vehicle national standard reflective signs and warning signs.
The medical waste truck has the functions of antibacterial, flame retardant, corrosion resistant, easy to clean and disinfect. Therefore, it is the preferred carrier for collection and distribution of medical waste in large, medium and small hospitals. Ideal for medical waste disposal and collection fleets.
